The new Yamaha NMAX is equipped with a range of exclusive features making it Yamaha’s premium and exclusive scooter in its class. A next generation scooter developed for a more prestigious and comfortable ride in the city. The NMAX is built from the MAX DNA to give the ideal balance of practically and functionality while offering elegance and comfort
Hotline :
604-2250028
NMAX / DUAL ABS
NMAX
OVERVIEW
COLORS AVAILABLE
ENGINE
| Type | Single Cylinder, Liquid-Cooled, 4-stroke, SOHC, 4-valve | |
| Displacement | 155 cm3 | |
| Bore x Stroke | 58.0 mm x 58.7 mm | |
| Compression Ratio | 11.6:1 | |
| Maximum Power | 11.3 kW (15.4PS)/8,000r/min | |
| Maximum Torque | 13.9N m (1.4kgf m)/6,000r/min | |
| Lubrication System | Force-Feed Lubrication, Wet Sump | |
| Fuel Supply System | Fuel-Injected | |
| Ignition System | TCI | |
| Starting System | Electric Starter | |
| Fuel Tank Capacity | 7.1L/1.9usgal/1.6lmp.gal |
TRANSMISSION
| Transmission system | V-Belt Automatic |
CHASIS
| Overall Length | 1,935 mm | |
| Overall Width | 740 mm | |
| Overall Height | 1,160 mm | |
| Seat Height | 765 mm | |
| Wheelbase | 1,340 mm | |
| Min. Ground Clearance | 125 mm | |
| Wet Weight | 130 kg |
BRAKES
| Front |
Hydraulic Single Disc, Ø 230 mm | |
| Rear | Hydraulic Single Disc, Ø 230 mm |
SUSPENSION
| Front Suspension | Telescopic | |
| Rear Suspension | Unit Swing |
TIRES
| Front | 110/70-13M/C 48P Tubeless | |
| Rear | 130/70-13M/C 63P Tubeless |
