CRF1100L AFRICA TWIN ADVENTURE SPORTS / DCT
COLORS AVAILABLE
CRF1100L AFRICA TWIN ADVENTURE SPORTS
OVERVIEW
The Honda 2020 CRF1100L Africa Twin Adventure Sports shares the frame, engine and riding position of the off-road focussed CRL1100L Africa Twin, but has a role very much own: to offer riders real continent-crossing long-haul ability and practicality both on and off-road.
ENGINE & TRANSMISSION
| Engine Code / Engine Type | Liquid-cooled, 4 stroke, OHC | Liquid-cooled, 4-stroke, 8-Valve, Parallel Twin with 270 Crank and Uni-Cam |
| Displacement ( Cm3 ) | 1084 | 1084 |
| Bore X Stroke (Mm) | 92.0 X 81.5 | 92.0 x 81.5 |
| Compression Ratio | 10.1 : 1 | 10.1 : 1 |
| Clutch | Assist / Slipper Clutch, Wet Multiplate with Coil Springs, Aluminum Cam | Assist / Slipper Clutch, Wet Multiplate with Coil Springs, Aluminum Cam |
| Transmission | 6 Speed manual, Mechanical (Chain drive) | 6 Speed Dual Clutch Transmission (DCT), Mechanical (Chain drive) |
| Starter | Electric | Electric |
FRAME, DIMENSION & WEIGHT
| Frame | Semi Double Cradle | Semi Double Cradle |
| Width X Length X Height (mm) | 2310 x 960 x 1520 (HI : 1580) | 2310 x 960 x 1520 (HI : 1580) |
| Wheelbase (mm) | 1560 | 1560 |
| Ground Clearance (mm) | 210 | 210 |
| Seat Height (mm) | 830 / 810 | 830 / 810 |
| Caster Weight (°/’) Angel / Trail (mm) | 27.5 | 27.5 |
| Curb Weight (KG) | 240 | 250 |
| Fuel Tank Capacity (Litres) | 24.8 | 24.8 (+0.5) |
SUSPENSION & TYRE
| Suspension |
Front : SHOWA 45mm Inverted Telescopic, Preload Adjustable
Rear : Pro-Link with SHOWA Gas Charged Damper Preload Adjuster, Swingarm |
Front : Telescopic
Rear : Pro-Link |
| Brakes |
Front : Dual Hydraulic Disk
Rear : Hydraulic Disk |
Front : Hydraulic Double Disk
Rear : Hydraulic Single Disk |
| Tyre |
Front : 90/90-21M/C 54H (Tubeless)
Rear : 150/70R18M/C 70H (Tubeless) |
Front: 90/90-21M/C 54H (Tubeless)
Rear: 150/70R18M/C 70H (Tubeless) |
PERFROMANCE
| Maximum Power | 75 kW / 7500 rpm | 75 kW / 7500 rpm |
| Maximum Torque | 105 N.m / 6250 rpm | 105 N.m / 6250 rpm |
