NX500

KB Soon Huat Motor Sdn Bhd > NX500
COLORS AVAILABLE

NX500

OVERVIEW

The Honda NX500 is a mid-weight adventure crossover motorcycle designed to balance everyday usability with long-distance touring capability. Replacing the CB500X, the NX500 carries forward Honda’s proven platform with upgraded styling, technology, and refined performance.

image-removebg-preview - 2026-04-01T181004.244
image-removebg-preview - 2026-04-01T181033.113
NX500 3
image-removebg-preview - 2026-04-01T181004.244
image-removebg-preview - 2026-04-01T181033.113
NX500 3
previous arrow
next arrow
motorcyyle certificate

ENGINE

  • Engine Type
          Liquid-cooled, 4-stroke DOHC Parallel Twin
  • Displacement (cm³)
          471 cm³
  • Bore x Stroke (mm)
           67.0 mm x 66.8 mm
  • Compression Ratio
           10.7 : 1
  • Max. Power (kW/rpm)

           37 kW / 8,500 rpm

  • Max. Torque (N.m/rpm)

          45 Nm / 6,500 rpm

  • Engine Oil Capacity

          2.4 ℓ (After draining)
3.1 ℓ (After disassembly)

CHASSIS

  • Frame Type
           Steel Diamond
  • Dimensions (L x W x H) (mm)
           2,165 mm x 830 mm x 1,415 mm
  • Wheelbase (mm)
           1,445 mm
  • Seat Height
          830 mm
  • Ground Clearance
           180 mm
  • Kerb Weight
           196 kg
