CT115S
COLORS AVAILABLE
CT115S
OVERVIEW
The CT-115S features a stylish design that is blessed with vibrant graphics that appeal to young riders. Powering this scooter is a 115cc air-cooled engine that makes 8.8hp of power and 8.1Nm of torque. The engine is paired to a 4-speed transmission setup. Suspension duties are carried out by telescopic forks on the front and unit swing arm on the rear. Stopping power comes from the disc brake at the front and drum brake on the rear.
ENGINE
| Type | 4 Stroke, SOHC, Single Cylinder |
| Bore X Stroke | 53.75 mm x 50.6 mm |
| Displacement | 114.8 cubic cm |
| Compression Ratio | 9.9 : 1 |
| Carburetor | SPACO, AV20 |
| Ignition System | Magneto CDI |
| Starting System | Primary Kick & Electric Starter |
| Cooling System | Air Cooled |
| Fuel Tank Capacity | 4.8 liter |
| Fuel Consumption | 80 km/j @ 46.8 |
TRANSMISSION
| Type | 4 Speed, Rotary |
| Clutch | Centrifugal |
| Primary Reduction Ratio | 3.048 |
| Final Reduction Ratio | 3.000 |
| Driving System | Drive Chain |
CHASSIS
| Type | Pipe Backbone, Steel Pipe |
| Front Suspension | Teleskopic Fork |
| Rear Suspension | Trailing Swing Arm |
| Front Brake | Disc |
| Rear Brake | Drum |
ELECTRICAL SYSTEM
Battery 12 V 5 Ah
